Main c haracteristics

• Direct and reverse energy measurement;
• Internal temperature sensor;
• Configurable digital inputs and outputs;
• Phasor diagram; waveform and bar graph of harmonics;
• Calendar and real-time clock;
• Programmable password to access the keyboard and parameter setting;
• Communication with RS485 isolated serial output, Modbus-RTU protocol;
• Identification on the display of the activated alarms;
• Pluggable connecting terminals for easy maintenance;
• Reading of Cos φ and power factor;
• Memory for 1,920 records of hourly parameters, 240 daily parameters and 36 monthly parameters for local reading or export via communication network;
• Simple and easy parameter setting via front keys or remotely using the parameter setting application and WEG converters;
• Phase sequence and phase loss identification and current and voltage presence indication;
• Energy measurements can be separated into two different periods;
• Connections to single-phase or three-phase star (3F + N) systems or three-phase delta (3F) systems.
